Output
- Type: servo-balanced
- Source impedance: 100Ω
- Min load impedance: 200Ω
- Max level: +23dBu
- Connectors: 1/4″ phone jack (TRS), XLR
Power requiremenets
- Nominal voltage: 220-240 vac (50-60 Hz)
- minimal voltage: 200 vac
- Power: 15w
Overall
- Frequency response: 31,5Hz-16KHz +0,25dB
- THD: <,01%@+20dBu
- IM distortion (SMPTE): <,01%@+20dBu
- Output hum & noise (unweighted): -94dBu
- Channel separation: >85db @1Khz
- Gain control: -10 to +10db
Filters
- Type: constant Q/ wein bridge
- Number: 15
- Bandwidth: 1/3 octave
- Tolerance: +3%
- Range: +6DB, +12dB (switchabel)
- Subsonic filter: 18dB/ octave @ 20-250Hz
